Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC

Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC
Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC

Large Image :  Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC

Product Details:
Place of Origin: CHINA
Brand Name: DOWE
Certification: CE,SGS
Model Number: 15 semi-enclosed Type
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: USD1-99
Packaging Details: CARTON
Delivery Time: 5-8DAYS
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 1000/DAY

Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC

Description
Name: Tow Chain Product Name: 15 Semi-enclosed Type
Inner Diameter: 15mm*30mm Outer Diameter: 20mm*40mm
Function: Machine Tool Accessories Bend Radius: R28/R38/R48
Temperature Range: -40 ~125 Material: PA66

Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC


Product Description
Product Name Plastic Tow Chain
Brand DOWE
Model 15 enclosed bridge type
Material PA66
Inner Diameter 15mm*30mm
Outer Diameter 20mm*40mm
Color customized
Sample free
Bengding Radius R28/R38/R48
Application Machine Tool Accessories
Certification CE,ROHS,UL for material
Operating Temperature -40℃~125℃
Place of Origin China



Plastic cable tow chain are designed to protect and convey cables,water pipes and air hoses on machine tools,robots and materials handling equipment.Nylon bridge cable chain threading is suitable for all kinds of small machanical equipmeng use,for wire ,cable,tubing,the trachea and conduit traction and protection.It is impact resistant with high strength and light in weight.The sturdy structure makes it not liable to distort.


Advantage:
1.Separate mounting bracket on both sides
2.Anti-corrosion,Rub-resistance,Gliding application
3.For high speed and high acceleration environment





15 R28 R38 R48
Inner H*D 15*15 15*20 15*30 15*40 15*50
Outer H*D 20*25 20*30 20*40 20*50 20*60





Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC 0Hot Sale Inner 15mmx30mm Semi-Enclosed Type Energy Plastic Cable Drag Chain Electric CNC 1

15
