Product Details:
|
Name: | Tow Chain | Product Name: | H20 Tow Chain |
---|---|---|---|
Function: | Machine Tool Accessories | Bend Radius: | R55/R100/R125/R150/R175 |
Temperature Range: | -40 ~125 | Material: | PA66 |
Highlight: | 20X38 cable drag chain suppliers,black cable drag chain suppliers,15mm x 30mm drag chain |
Product Name | Plastic Tow Chain |
Brand | DOWE |
Model | H20 tow chain |
Material | PA66 |
Inner Diameter | 20mm*38mm |
Outer Diameter | 35mm*56mm |
Color | black |
Sample | sample fee refund from 1st order |
Bengding Radius | R55/R75/R100/R125/R150/R175 |
Application | Machine Tool Accessories |
Certification | CE,SGS |
Operating Temperature | -40℃~125℃ |
Place of Origin | China |
H20 R55 R75 R100 R125 R150 R175 | |||||||
Inner H*D | 20*25 | 20*38 | 20*50 | 20*57 | 20*60 | 20*77 | 20*103 |
Outer H*D | 35*43 | 35*56 | 35*68 | 35*75 | 35*78 | 35*95 | 35*121 |
Plastic cable tow chain are designed to protect and convey cables,water pipes and air hoses on machine tools,robots and materials handling equipment.Nylon bridge cable chain threading is suitable for all kinds of small machanical equipmeng use,for wire ,cable,tubing,the trachea and conduit traction and protection.It is impact resistant with high strength and light in weight.The sturdy structure makes it not liable to distort.
Advantage:
1.Separate mounting bracket on both sides
2.Anti-corrosion,Rub-resistance,Gliding application
3.For high speed and high acceleration environment
